2025 Isuzu F Series

Isuzu FSD 140/120-240 AM R56

Engine: Isuzu 4HK1-TCH| 5.2L 4 Cylinder Turbo Diesel
Transmission: Isuzu MZW-6P | 6 Speed Automated Manual Transmission

Power: 240 Hp | 177 kW @ 2,400 RPM
Torque: 765 Nm @ 1,600 RPM

Weight Rating: GVM: 11,000 Kg GCM: 18,500 Kg
Wheelbase: 5,560 mm

Transport Refrigeration Services

Thermaxx Advantage A6500P 10 Pallet Insulated Body
SPECIFICATIONS
K VALUE: .57 W/m2K tested to Australian Standard AS4982
EXTERNAL LENGTH: 6500mm
INTERNAL WIDTH: 2410mm
INTERNAL HEIGHT: 2200mm
PALLET LOADING: 10 Pallet Capacity
APPROX WEIGHT: 2405kg*
ROOF, FLOOR & FRONT WALL THICKNESS: 100mm
REAR DOOR THICKNESS: 80mm
SIDE WALL THICKNESS: 40mm
SIDE DOOR: Passenger Side Pallet Width Double Door
2200x1400mm (HxW) Left Opens First
REAR DOOR: Double Rear - Left Opens First
FRONT WALL FRAME: Universal to suit Diesel Engine Drive units
CARGO TRACK: 1 Recessed Row at 1000mm on Side Walls and 1
Shoring Bar
FLOOR: One Piece Hi-Tensile Alloy Rice Grain Floor
RUNNERS: 150mm Steel Main Subframe Runners
INTERNAL LIGHTS: 2 LED Sensor Lights
K VALUE BENEFITS:
- Increased thermal efficiencies of your body
- Tested to Australian Standards
- Reduce the running cost of your vehicles
REFRIGERATION RECOMMENDATION: Chiller/Freezer - Thermo
King T-1000R
STANDARD INCLSUIONS
High Density Polyurethane Insulation - European Design -
European Construction - Low Tare Weight - Higher Legal Payload
- Hot Dipped Galvanised Sub Frame - Recessed Stainless Steel
Door Hardware - Stainless Steel Door Frames - Anodised Corner
Mouldings - Long Life EPDM Rubber Seals - Internal LED Sensor
Light - Rubber Bump Stops - Rear/Side Grab Handles - Recessed
Load Restraint Track - Moulded Plastic Mud Guards - Alloy Kick
Panel -Standard Fixed Rung Pallet Width Side Step to suit bodies
Standard Rear Galvanised Mid Size Heavy Duty Crash Bar
Thermo King Diesel/Electric T-1000R Truck Refrigeration Unit
STANDARD FEATURES
REFRIGERANT GAS: R452A or R404A
APPLICATION TYPE: Freezer
UNIT WEIGHT: 514kg
STAND-BY: Included
STAND-BY PLUG: Located on the passenger side front wall
VOLTAGE: 3 Phase / 415 Volts
COMPRESSOR: X426 C5 Reciprocating Compressor
ENGINE: Low Emission, Liquid Cooled TK 376
Warranty :
Thermo King T-1000 Units come with a 24 Month Warranty
All New Thermaxx Advantage Equipment is warranted for 5 Years in the case of faulty materials and workmanship, including
the Aluminium Rice Grain Floor


Advanced Safety Features:

Advanced Emergency Braking (AEB)
Adaptive Driving Beam (ADB)
Anti Lock Braking System (ABS)
Anti Skid Regulator (ASR)
Attention Alert System (AAS)
Auto Lighting System (ALS)
Cab Tilt Warning (CTW)
Customisable Speed Limiter (CSL)
Distance Warning System (DWS)
Electronic Stability Control (ESC)
Forward Collision Warning (FCW)
Full Speed Adaptive Cruise Control
(FACC)
Intelligent Speed Limiter (ISL)
Lane Departure Warning (LDW)
Traffic Movement Warning (TMW)
Traffic Sign Recognition (TSR)

Passive Safety Cabin Occupant Safety Safety (COSS)

Door Mounted Cornering Lamps
Driver and Front Left Hand Passenger
Seatbelt Pretensioners
Driver and Front Passenger Airbags
ECE-R29 Cab with Side Anti-Intrusion Beams
Overhead storage compartments with doors.

Standard Features:

ADR 80/04 Euro VI Compliant
Emissions - SCR - Selective Catalytic Reduction) & DPD (Diesel Particulate Diffuser)
Jacobs Engine Compression Brake
Electronically Controlled Variable Nozzle Turbocharger
Direct Injection High Pressure Common Rail System
200L Frame Mounted Lockable Steel Fuel Tank
90° Opening Internally Reinforced Doors
Heated and Power Adjusted Top Mirrors and Bottom Convex Spot Mirrors
Central Locking with Remote Entry and Immobiliser
Driver's ISRI 6860/875 NTS Air Suspension Seat
10.1" 1080p High-Definition Audio Visual Unit with Capacitive Touch
Truck Tailored GPS Based System
Android Auto / Apple CarPlay Compatible
USB 3.0 Socket


Warranty:
6 Year Standard Warranty | 300,000 Km | Unlimited Hours (Whichever Comes First)

Genuine Accessory and RTW Equipment Warranty:
3 Year Standard Warranty | Unlimited Km | Unlimited Hours

Aftermarket Accessory and Body Warranty:
12 Month Standard Warranty | Unlimited Hours

Roadside Assistance:
6 Year Roadside Support 24/7 | Unlimited Km

Please Note: If warranty period may differ depending on harsh application (4x4, AWD, Agitator, Compactor, etc
