2025 Isuzu N Series

In Stock Now!

Weight Ratings
GVM 4,500 kg / 6,500 kg
GCM1 (with DT) 8,000 kg
Towing Capacity1 (at
4,500kg GVM rating)
4,500 kg
Engine
Power 129 kW @ 2,860 rpm
Torque 430 Nm @ 1,450 - 2,860 rpm
Transmissions
6-speed Manual Transmission (MT)
9-speed Dual-clutch Transmission (DT)
Wheelbase
2,795 mm
3,395 mm
ReadytoWork
Features
Black powder coated lockable underbody mounted storage box
Corner stirrup with moulded thread plate
External ratchet rails - rated 600 kg each
Fold down ear system
Heavy duty aluminium ladder racks (combined rating with headboard
250kg)
Heavy duty truck aluminium deck - rated to 5 tonne
Isuzu Genuine Bullbar
Isuzu Genuine Towbar
Metal encapsulated glass fibre reinforced nylon catches
New & improved quick lock hinge system
Powder Coated Window Protector and tail light protector
Removable dropsides and tailgate with cargo seal for easy tiedown
access and load retainment
Tube headboard with grab handles
Underbody mounted 25L water tank and soap dispenser

Engine
Description Isuzu 4JZ1-TCH
Type 4 Cylinder
Power 129 kW @ 2,860 rpm
Torque 430 Nm @ 1,450 - 2,860 rpm
Displacement 2,999 cc
Compression Ratio 17.50:1
Bore x Stroke 95 mm x 104 mm
Induction Electronically controlled variable nozzle
turbocharger with air -to air intercooler.
Fuel Injection Direct injection high pressure common rail
system
Emission Standard ADR 80/04 (pPNLT)
Emission Control
SCR (Selective Catalytic Reduction)
DPD (Diesel Particulate Diffuser)
EGR (Exhaust Gas Recirculation)
Auxiliary Brake Vacuum controlled exhaust brake

Transmission
DT
Description: Isuzu MYR-9S
Type: 9-speed Dual-clutch Transmission (DT) with both fully
automatic and clutchless manual operation modes
Ratios:
1 2 3 4 5 6 7 8 9 REV
5.16 3.94 2.86 2.18 1.67 1.30 1.00 0.76 0.58 4.81
Power Take Off Facility: Provision on LHS of transmission case.
Drive from counter gear.

Intelligent Safety
ACTIVE SAFETY
Advanced Driver
Assistance
Systems (ADAS)
Advanced Emergency Braking (AEB)
Anti-lock Braking System (ABS)
Anti-Skid Regulator (ASR)
Attention Alert System (AAS)
Automatic Lighting System (ALS)
Cab Tilt Warning (CTW)
Cruise Control (CC)
Distance Warning System (DWS)
Electric Park Brake (EPB)
Electronic Brakeforce Distribution (EBD)
Electronic Stability Control (ESC)
Front Cross Traffic Alert (FCTA)
Full Speed Adaptive Cruise Control (F-ACC)
(DT only)
Intelligent Speed Limiter (ISL) (DT only)
Intersection Emergency Braking (IEB)
Intersection Warning System (IWS)
Lane Departure Warning (LDW)
Miss Acceleration Mitigation (MAM) (DT only)
Traffic Movement Warning (TMW)
Traffic Sign Recognition (TSR) (DT only)
PASSIVE SAFETY
Cabin Occupant
Safety Systems
(COSS)
Door mounted cornering lamps
Driver and front left hand passenger seatbelt
pretensioners
Driver and front passenger airbags
ECE-R29 cab with side anti-intrusion beams
Overhead shelf restraint netting
