2026 Isuzu FY Series

ISUZU FYJ 320-355 AT R60

Heavy Duty 8x4 Cab Chassis
______________________________________
VEHICLE OVERVIEW

Model: FYJ 320-355 AT R60
GVM: 32,000 kg
GCM: 45,000 kg
Wheelbase: 6,010 mm
Engine: Isuzu 6UZ1-TCC 6 Cylinder Turbo Diesel
Power: 259 kW @ 2,000 rpm
Torque: 1,437 Nm @ 1,400 rpm
Transmission: Allison 4430 GEN 6 6-Speed Automatic Transmission (AT)
________________________________
West-Trans Equipment HL-22A Articulating Jib Hook Lift

Capacity 22 Tonne WLL
Jib Type Articulating jib
Bin Range 3500mm-6800mm
Controls Scanreco electric over air controls
PTO/Pump for Allison automatic Transmission
Oil Tank/Filter Padoan aluminium type oil tank with integrated return filter mounted on front of hook lift behind the cab
Hook Height 1450/1550/1650 mm manually adjustable
Tunnel Height 90mm
Rail Width 1060mm, outside as standard
Outer Locks Hydraulic bin locking hooks operating over outside bottom flange of bin rail
Body Colour Painted in 2 pack jet black
Rear Light Bar LED lights at rear with LED side markers
Guards Black plastic guards
600mm x 450mm x 450mm black tool box
LED work lights x 2 on tarp tower, x 4 at rear
Single Narva LED Slimline beacon
Hycover Tower (HL18/20) Tarping System
Broom Holder & Shovel Holder

FEATURES

ADR 80/04 (Euro VI) Compliant
Adaptive Driving Beam (ADB)
Bi-LED Headlamps with Daytime Running Lamps (DRL)
Electronic Stability Control (ESC)
Full Speed Adaptive Cruise Control (FACC)
ISRI 6860/875 NTS2 Air Suspension Driver's Seat
Lane Departure Warning (LDW)
Lane Keeping Assist (LKA)

CHASSIS

Front Axle Capacity: 14,600 kg
Rear Axle Capacity: 20,000 kg
Fuel Tank: 400 L Aluminium
AdBlue Tank: 28 L High-Density Polyethylene
1st Steer Axle Tyres: 295/80R22.5 152/148M Michelin X Multi Z2
2nd Steer Axle Tyres: 295/80R22.5 152/148M Michelin X Multi Z2
Rear Axle Tyres: 11R22.5 148/145L Michelin

CABIN

Automatic Climate Control
ISRI 6860/875 NTS2 Air Suspension Driver's Seat with Heating and Ventilation
10.1" High Definition Touchscreen
Truck Tailored GPS Navigation with Live Traffic and Map Content Updates
Android Auto & Apple CarPlay Compatible
Wi Fi Connectivity
Bi LED Headlamps with Daytime Running Lamps (DRL)
LED Front Fog Lamps
LED Tail Lamps
Reverse Alarm

WARRANTY & SERVICE

Chassis Warranty: 6 Years / 600,000 km / 10,000 Engine Hours
Service Interval: 25,000 km / 12 Months / 500 Hours (Whichever Occurs First)
Roadside Assist: 6 Years / 24/7 Unlimited km
